VNH7013XP-E

Manufacturers:	STMicroelectronics
Product Category:	PMIC - Full, Half-Bridge Drivers
Data Sheet:	VNH7013XP-E
Description:	IC MOTOR DRIVER PAR 36POWERSSO
RoHS status:	RoHS Compliant

Product Description
Customer Reviews

Attribute	Attribute Value
Manufacturer	STMicroelectronics
Product Category	PMIC - Full, Half-Bridge Drivers
Series	VIPower™
Features	-
Interface	Logic
Load Type	Inductive
Packaging	Tube
Technology	Power MOSFET
Part Status	Active
Applications	DC Motors, General Purpose
Rds On (Typ)	7.3mOhm LS, 5.7mOhm HS
Mounting Type	Surface Mount
Package / Case	36-PowerBFSOP (0.295", 7.50mm Width)
Voltage - Load	-
Base Part Number	VNH7013
Fault Protection	Over Temperature
Voltage - Supply	72V (Max)
Output Configuration	Half Bridge (2)
Current - Peak Output	-
Operating Temperature	-40°C ~ 175°C (TJ)
Supplier Device Package	PowerSSO-36
Current - Output / Channel	40A
