Image is for reference only , See Product Specifications
PD20-1-1210
| Manufacturers: | TRINAMIC Motion Control GmbH |
|---|---|
| Product Category: | Stepper Motors |
| Data Sheet: | PD20-1-1210 |
| Description: | PANDRIVE NEMA08, 24V, 1.75NCM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | TRINAMIC Motion Control GmbH |
| Product Category | Stepper Motors |
| Type | Hybrid |
| Series | PANdrive™ |
| Accuracy | ±5% |
| Features | Integrated Controller, Round Shaft |
| Approvals | - |
| Coil Type | Bipolar |
| Step Angle | 1.8° |
| Part Status | Active |
| Rotor Inertia | 2gcm² |
| Coil Resistance | 6.5 Ohms |
| NEMA Frame Size | 8 |
| Voltage - Rated | 24VDC |
| Diameter - Shaft | 0.157" (4.00mm) |
| Size / Dimension | Square - 0.787" x 0.787" (20.00mm x 20.00mm) |
| Termination Style | Connector |
| Steps per Revolution | 200 |
| Current Rating (Amps) | 600mA |
| Mounting Hole Spacing | 0.630" (16.00mm) |
| Operating Temperature | -20°C ~ 50°C |
| Length - Shaft and Bearing | 0.591" (15.00mm) |
| Torque - Holding (oz-in / mNm) | 2.48 / 17.5 |
New and Original electronic components PD20-1-1210 from Huge inventory, fast shipment, Lanka Micro electronics website accept order online、BOM list quotation, and accept various payment term. Right now register as our member,you can get lots of discounts. For any inquiry, welcome to send email to us, or leave a message. ![lanka micro cooperation]()
Lanka Micro Electronic Co.,Limited is a global electronic components distributor. Since company was founded, we always uphold 'best product, best reputation,best service, reasonable price' business philosophy, based on professional quality and consistent professionalism, we win trust and support from the majority of suppliers and customers, and rapidly rising in the fierce market competition.
In Stock 31 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $156.30 | $153.17 | $150.11 |
Minimum: 1
